Hot Rolled Mild Steel NM400 NM450 NM500 Wear Resistant Steel Plate

Common Models

AR Series: AR400, AR450, AR500, AR600 (increasing hardness)

NM Series: NM400, NM500 (corresponding to AR400/AR500, compliant with JIS standards)

HB Series: HB400, HB500 (high-strength, wear-resistant steel)

XAR Series: XAR400 (similar performance to NM400)

Main Materials

Carbon Steel Alloy: Contains elements such as manganese (Mn) and chromium (Cr); for example, NM400 contains 1.2-1.6% Mn.

Special Treatment: Some models are hardened through quenching and tempering (such as AR500).

Applications
Engineering machinery, mining equipment, shipbuilding, etc.

Product Name	Prime Quality VRN400 VRN500 1200*2500mm AR500 Hard Wearing and Abrasion Resistant Steel Plate 10mm 14mm 16mm Wear Plate Price
Grade	China: NM360,NM400,NM450,NM500 etc Germany: Xar400, Xar450, Xar500,Xar550, Xar600 Finland: RAEX400,RAEX450,RAEX500DIN: CREUSABRO48000 CREUSABRO8000
Surface	natural color coated galvanized or customized
Standard	DIN GB JIS BA AISI ASTM EN etc
Certificate	MTC SGS
Technique	hot rolled or cold rolled
Thickness	3-200mm or as required
Width	1500-2000mm or as required
Length	6000-12000mm or as required
Application	This kind of steel has a good resistance to abrasion, so it is widely used in engineering machinery, metallurgical machinery, coal industry, mining machinery,environmental protection machinery,the feeder,container,dumper bodies, sieve plate,hoister,edge plate,wheel gear,cutter etc other industry.
MOQ	5 Metric tons
Delivery time	Within 7-15 workdays after receiving deposit or L/C
Export packing	Steel strips package or seaworthy packing
Capacity	250,000 tons/year
Payment	T/T L/C, Western Union
Should have any questions, please contact me .I will do my best to help you.

Wear-resistant steel plate are typically available in different hardness levels, such as NM360, NM400, NM450, and NM500, with the numbers representing the Brinell hardness (HB) values. The higher the number, the higher the hardness and wear resistance of the material.

Mechanical property
Grade	Surface Brinell Hardness(HBW)	TensileStrength(MPa)	Elongation A(%)	Impact energy(-20℃, J)
NM360	340-400	≥1000	≥14	≥24
NM400	370-430	≥1200	≥12	≥24
NM450	420-480	≥1400	≥10	≥20
NM500	480-540	≥1550	≥8	≥15
NM550	530-600	≥1750	≥7	≥12
NM600	≥570	≥1900	≤8	≥10

Steel/Grade	C	Si	Mn	P	S	Al	Cr+Ni+Mo	Nb+V+Ti
NM360/AR360	0.10-0.30	0.20-0.40	1.00-2.00	≤0.0015	≤0.003	≥0.20	＜0.6	Trance Amount
NM400/AR400	0.10-0.40	0.20-0.40	1.00-2.00	≤0.0015	≤0.003	≥0.20	＜0.9
NM450/AR450	0.10-0.40	0.20-0.40	1.00-2.00	≤0.0015	≤0.003	≥0.20	＜1.2
NM500/AR500	0.10-0.40	0.20-0.45	1.00-2.00	≤0.0015	≤0.003	≥0.20	＜1.5
NM550/AR550	0.10-0.50	0.20-0.45	1.00-1.50	≤0.0015	≤0.003	≥0.20	＜2.0
NM600/AR600	0.10-0.50	0.20-0.45	1.00-1.50	≤0.0015	≤0.003	≥0.20	＜2.5
